Terex
Caterpillar
773G
Off-Highway Truck
12 specifications
1 / 5
Image 1 of 5
Specifications
32 data points
Operating Specifications
| Fuel Capacity | 799.9 gal |
|---|---|
| Tire Size | 40.00R57 radial |
| Engine Oil Capacity | 66.1 gal |
| Cooling System Fluid Capacity | 156.2 gal |
| Hydraulic System Fluid Capacity | 239.9 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 220 A |
Engine
| Engine Model | QSK60 |
|---|---|
| Gross Power | 2,500.0 hp |
| Net Power | 2,287.0 hp |
| Number of Cylinders | 16 |
| Aspiration | 220 amps |
| Rated Engine Speed | 240 rpm |
Weights
| Empty Weight | 355,000 lb |
|---|---|
| Loaded Weight | 862,000 lb |
| Weight Distribution Front - loaded | 33.0 % |
| Weight Distribution Rear - loaded | 67.0 % |
| Weight Distribution Front - empty | 48.0 % |
| Weight Distribution Rear - empty | 52.0 % |
Dimensions
| Wheelbase | 252 in |
|---|---|
| Overall Length | 548 in |
| Overall Width | 316 in |
| Overall Height | 284 in |
| Dump Height | 504 in |
| Dump Ground Clearance | 72 in |
Transmission
| Max Speed | 29.9 mph |
|---|
Service Refill Capacities
| Brake/Hoist Hydraulic Tank | 479,947.7 gal |
|---|
Dump
| Dump Angle | 45 ° |
|---|---|
| Raise Time | 22.0 s |
| Lower Time | 15.0 s |
| Load Capacity - heaped | 188.40 yd³ |
| Load Capacity - Struck | 130.80 yd³ |
