773G
Off-Highway Truck
12 specifications
1 / 5
Image 1 of 5
Specifications
32 data points
Operating Specifications
| Fuel Capacity | 799.9 gal |
|---|---|
| Tire Size | 50/80R57 Radial |
| Engine Oil Capacity | 61.1 gal |
| Cooling System Fluid Capacity | 156.2 gal |
| Hydraulic System Fluid Capacity | 239.9 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 100 A |
Engine
| Engine Model | QSK60 2-Stage |
|---|---|
| Gross Power | 2,700.0 hp |
| Net Power | 2,487.0 hp |
| Number of Cylinders | 16 |
| Aspiration | 100 amps |
| Rated Engine Speed | 240 rpm |
Weights
| Empty Weight | 377,000 lb |
|---|---|
| Loaded Weight | 865,000 lb |
| Weight Distribution Front - loaded | 33.0 % |
| Weight Distribution Rear - loaded | 67.0 % |
| Weight Distribution Front - empty | 49.6 % |
| Weight Distribution Rear - empty | 50.4 % |
Dimensions
| Wheelbase | 252 in |
|---|---|
| Overall Length | 556 in |
| Overall Width | 316 in |
| Overall Height | 280 in |
| Dump Height | 500 in |
| Dump Ground Clearance | 67 in |
Transmission
| Max Speed | 39.8 mph |
|---|
Service Refill Capacities
| Brake/Hoist Hydraulic Tank | 479,947.7 gal |
|---|
Dump
| Dump Angle | 45 ° |
|---|---|
| Raise Time | 22.0 s |
| Lower Time | 15.0 s |
| Load Capacity - heaped | 188.40 yd³ |
| Load Capacity - Struck | 130.80 yd³ |
