Komatsu
960E-1
Off-Highway Truck
35 specifications
1 / 5
Image 1 of 5
Specifications
33 data points
Operating Specifications
| Fuel Capacity | 799.9 gal |
|---|---|
| Tire Size | 55/80R63 radial |
| Engine Oil Capacity | 66.1 gal |
| Cooling System Fluid Capacity | 156.2 gal |
| Hydraulic System Fluid Capacity | 320.0 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 100 A |
Engine
| Engine Model | QSK60 2 Stage |
|---|---|
| Gross Power | 2,700.0 hp |
| Net Power | 2,478.0 hp |
| Number of Cylinders | 16 |
| Aspiration | 100 amps |
| Rated Engine Speed | 320 rpm |
Weights
| Empty Weight | 478,000 lb |
|---|---|
| Loaded Weight | 1,198,000 lb |
| Weight Distribution Front - loaded | 33.2 % |
| Weight Distribution Rear - loaded | 66.8 % |
| Weight Distribution Front - empty | 48.0 % |
| Weight Distribution Rear - empty | 52.0 % |
Dimensions
| Ground Clearance | 41 in |
|---|---|
| Wheelbase | 263 in |
| Overall Length | 582 in |
| Overall Width | 373 in |
| Overall Height | 302 in |
| Dump Height | 529 in |
| Dump Ground Clearance | 71 in |
Transmission
| Max Speed | 40.4 mph |
|---|
Service Refill Capacities
| Brake/Hoist Hydraulic Tank | 719,921.6 gal |
|---|
Dump
| Dump Angle | 45 ° |
|---|---|
| Raise Time | 28.0 s |
| Lower Time | 12.0 s |
| Load Capacity - heaped | 285.19 yd³ |
| Load Capacity - Struck | 206.70 yd³ |
