Terex
Caterpillar
5130B
Mini Excavator
16 specifications
1 / 5
Image 1 of 5
Specifications
38 data points
Operating Specifications
| Fuel Capacity | 1,415.8 gal |
|---|---|
| Hydraulic System Fluid Capacity | 660.4 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 300 A |
| Swing Speed | 5 rpm |
Engine
| Engine Model | 2x C18 |
|---|---|
| Displacement | 1,105 in³ |
| Power Measured @ | 1,800 rpm |
| Gross Power | 1,568.0 hp |
| Net Power | 1,400.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged and charge air cooled |
Dimensions
| Height - Top of Cab | 300 in |
|---|---|
| Length of Track on Ground | 236 in |
| Upper Structure Ground Clearance | 85 in |
| Length of Tracks | 301 in |
| Height of Tracks | 77 in |
Undercarriage
| Track Gauge | 190 in |
|---|---|
| Max Travel Speed | 1.7 mph |
| Number of Upper Rollers | 2 |
| Loading Shovel Operating Weight | 626,333 lb |
| Loading Shovel Shoe Width | 39 in |
| Loading Shovel Ground Pressure | 31 psi |
| Number of Lower Rollers | 7 |
| Backhoe Shoe Width 1 | 39 in |
| Backhoe Operating Weight - Shoe 1 | 632,947 lb |
| Backhoe Ground Pressure - Shoe 1 | 31 psi |
| Number of Track Shoes per Side | 47 |
| Tail Swing Radius | 250 in |
Bucket
| Reference Bucket Capacity | 20.19 yd³ |
|---|---|
| Maximum Bucket Capacity | 22.30 yd³ |
| Minimum Bucket Capacity | 17.70 yd³ |
Loading Shovel
| Max Dig Depth | 100 in |
|---|---|
| Max Dig Reach | 540 in |
| Max Cutting Height | 548 in |
| Max Dump Height | 422 in |
Backhoe Boom / Stick 1
| Max Dig Depth | 241 in |
|---|---|
| Max Cutting Height | 568 in |
