Terex

RH170B

Mini Excavator

Gross Power
2,032.0 hp
Net Power
2,032.0 hp
All mini excavators
Terex RH170B Mini Excavator
1 / 5
Image 1 of 5
Image: marketbook.com.na

Specifications

30 data points

Operating Specifications

Operating Specifications specifications
Fuel Capacity2,060.4 gal
Hydraulic System Fluid Capacity792.5 gal
Operating Voltage24 V
Alternator Supplied Amperage300 A
Swing Speed5 rpm

Engine

Engine specifications
Engine Model2x C32
Displacement1,959 in³
Power Measured @1,750 rpm
Gross Power2,032.0 hp
Net Power2,032.0 hp
Number of Cylinders12
AspirationTurbocharged and air to air aftercooled

Dimensions

Dimensions specifications
Height - Top of Cab311 in
Length of Track on Ground245 in
Upper Structure Ground Clearance101 in
Length of Tracks318 in
Height of Tracks88 in

Undercarriage

Undercarriage specifications
Track Gauge214 in
Max Travel Speed1.7 mph
Number of Upper Rollers2
Loading Shovel Operating Weight868,180 lb
Loading Shovel Shoe Width47 in
Loading Shovel Ground Pressure34 psi
Number of Lower Rollers7
Number of Track Shoes per Side42
Tail Swing Radius268 in

Loading Shovel

Loading Shovel specifications
Max Dig Depth103 in
Max Dig Reach607 in
Max Cutting Height568 in
Max Dump Height430 in
