Terex
Hitachi
EX5500-5
Mini Excavator
46 specifications
1 / 5
Image 1 of 5
Specifications
37 data points
Operating Specifications
| Fuel Capacity | 2,819.7 gal |
|---|---|
| Hydraulic System Fluid Capacity | 1,611.3 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 350 A |
| Swing Speed | 4 rpm |
Engine
| Engine Model | 2x K 1500-E |
|---|---|
| Displacement | 2,300 in³ |
| Power Measured @ | 1,800 rpm |
| Gross Power | 2,520.0 hp |
| Net Power | 2,520.0 hp |
| Number of Cylinders | 24 |
| Aspiration | Turbocharged and aftercooled |
Dimensions
| Height - Top of Cab | 346 in |
|---|---|
| Length of Track on Ground | 252 in |
| Upper Structure Ground Clearance | 110 in |
| Length of Tracks | 337 in |
| Height of Tracks | 98 in |
Undercarriage
| Track Gauge | 221 in |
|---|---|
| Max Travel Speed | 2.3 mph |
| Number of Upper Rollers | 2 |
| Loading Shovel Operating Weight | 1,157,427 lb |
| Loading Shovel Shoe Width | 55 in |
| Loading Shovel Ground Pressure | 37 psi |
| Number of Lower Rollers | 6 |
| Backhoe Shoe Width 1 | 55 in |
| Backhoe Operating Weight - Shoe 1 | 1,183,883 lb |
| Backhoe Ground Pressure - Shoe 1 | 38 psi |
| Number of Track Shoes per Side | 39 |
Bucket
| Reference Bucket Capacity | 27.49 yd³ |
|---|---|
| Maximum Bucket Capacity | 39.89 yd³ |
| Minimum Bucket Capacity | 27.49 yd³ |
Loading Shovel
| Max Dig Depth | 95 in |
|---|---|
| Max Dig Reach | 639 in |
| Max Cutting Height | 602 in |
| Max Dump Height | 466 in |
Backhoe Boom / Stick 1
| Max Dig Depth | 362 in |
|---|---|
| Max Cutting Height | 670 in |
