Terex

RH340

Mini Excavator

Gross Power
2,520.0 hp
Net Power
2,520.0 hp
All mini excavators
Terex RH340 Mini Excavator
1 / 5
Image 1 of 5
Image: constructionscalemodels.com

Specifications

37 data points

Operating Specifications

Operating Specifications specifications
Fuel Capacity2,826.4 gal
Hydraulic System Fluid Capacity1,611.3 gal
Operating Voltage24 V
Alternator Supplied Amperage350 A
Swing Speed4 rpm

Engine

Engine specifications
Engine Model2 x K 1500-E
Displacement2,300 in³
Power Measured @1,800 rpm
Gross Power2,520.0 hp
Net Power2,520.0 hp
Number of Cylinders24
AspirationTurbocharged and aftercooled

Dimensions

Dimensions specifications
Height - Top of Cab346 in
Length of Track on Ground280 in
Upper Structure Ground Clearance110 in
Length of Tracks364 in
Height of Tracks100 in

Undercarriage

Undercarriage specifications
Track Gauge221 in
Max Travel Speed1.3 mph
Number of Upper Rollers2
Loading Shovel Operating Weight1,216,952 lb
Loading Shovel Shoe Width55 in
Loading Shovel Ground Pressure31 psi
Number of Lower Rollers7
Backhoe Shoe Width 155 in
Backhoe Operating Weight - Shoe 11,205,929 lb
Backhoe Ground Pressure - Shoe 131 psi
Number of Track Shoes per Side42

Bucket

Bucket specifications
Reference Bucket Capacity36.70 yd³
Maximum Bucket Capacity44.50 yd³
Minimum Bucket Capacity36.70 yd³

Loading Shovel

Loading Shovel specifications
Max Dig Depth103 in
Max Dig Reach642 in
Max Cutting Height607 in
Max Dump Height454 in

Backhoe Boom / Stick 1

Backhoe Boom / Stick 1 specifications
Max Dig Depth350 in
Max Cutting Height626 in
