PC1250LC-7
Mini Excavator
4 specifications
1 / 5
Image 1 of 5
Specifications
33 data points
Operating Specifications
| Fuel Capacity | 435.9 gal |
|---|---|
| Hydraulic System Fluid Capacity | 396.3 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 150 A |
| Swing Speed | 6 rpm |
Engine
| Engine Model | C 18 |
|---|---|
| Displacement | 1,105 in³ |
| Power Measured @ | 1,800 rpm |
| Gross Power | 700.0 hp |
| Net Power | 665.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged and charge air cooled |
Dimensions
| Height - Top of Cab | 227 in |
|---|---|
| Length of Track on Ground | 204 in |
| Upper Structure Ground Clearance | 70 in |
| Length of Tracks | 254 in |
| Height of Tracks | 62 in |
Undercarriage
| Track Gauge | 166 in |
|---|---|
| Max Travel Speed | 1.5 mph |
| Number of Upper Rollers | 3 |
| Number of Lower Rollers | 9 |
| Backhoe Shoe Width 1 | 24 in |
| Backhoe Operating Weight - Shoe 1 | 268,964 lb |
| Backhoe Ground Pressure - Shoe 1 | 26 psi |
| Number of Track Shoes per Side | 52 |
| Backhoe Shoe Width 2 | 30 in |
| Backhoe Ground Pressure - Shoe 2 | 21 psi |
| Backhoe Operating Weight - Shoe 2 | 272,712 lb |
| Backhoe Shoe Width 3 | 36 in |
| Backhoe Ground Pressure - Shoe 3 | 18 psi |
| Backhoe Operating Weight - Shoe 3 | 276,460 lb |
Backhoe Boom / Stick 1
| Max Dig Depth | 288 in |
|---|---|
| Max Cutting Height | 489 in |
