Terex
Tadano
TR-600XXL-4
Rough Terrain Crane
Specifications pending
1 / 5
Image 1 of 5
Specifications
27 data points
Operating Specifications
| Fuel Capacity | 79.3 gal |
|---|---|
| Tire Size | 16.00-25 |
| Operating Voltage | 24 V |
Engine
| Engine Model | QSB6.7 |
|---|---|
| Power Measured @ | 2,200 rpm |
| Gross Power | 173.0 hp |
| Torque Measured @ | 1,500 rpm |
| Max Torque | 590 lb-ft |
| Engine Make | Cummins |
Dimensions
| Ground Clearance | 28 in |
|---|---|
| Wheelbase | 154 in |
| Transport Width | 100 in |
| Transport Height | 133 in |
| Transport Length | 458 in |
| Width w/ Outriggers Extended | 236 in |
| Upper Structure Tail Swing Radius | 144 in |
| Carrier/Base Length | 275,827 in |
Transmission
| Max Speed - Forward | 19.7 mph |
|---|---|
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
| Transmission Type | Powershift Manual |
General Specifications
| Lift Capacity Tons (metric tons) | 45 (49.6) — Starting 2017 Model Year |
|---|---|
| Lift Height Ft. (m) | 33 (108.3) — Starting 2017 Model Year |
Boom
| Max Height @ Max Raise Angle - no jib | 1,225 in |
|---|---|
| Min Height @ Max Raise Angle | 386 in |
| Max Elevating Angle | 78 ° |
| Number of Sections | 4 |
