Terex

SKL823

Wheel Loader

Operating Weight
8,598 lb
Net Power
49.7 hp
All wheel loaders
Terex SKL823 Wheel Loader
1 / 5
Image 1 of 5
Image: truck1.eu

Specifications

23 data points

Operating Specifications

Operating Specifications specifications
Operating Weight8,598 lb
Fuel Capacity19.1 gal
Tire Size365/70 R 18 SPT 9
Hydraulic System Fluid Capacity16.2 gal
Operating Voltage12 V
Engine Oil Fluid Capacity2.2 gal
Rear Axle Oscillation12 °
Front Axle/Diff Fluid Capacity1.8 gal
Rear Axle/Diff Fluid Capacity1.8 gal
Transmission Fluid Capacity0.4 gal

Engine

Engine specifications
Displacement183 in³
Net Power49.7 hp
Number of Cylinders4
Engine MakePerkins
Net Torque137 lb-ft

Hydraulic System

Hydraulic System specifications
Lower Time3.6 s
Dump Time1.1 s

Dimensions

Dimensions specifications
Ground Clearance18 in
Height - Top of Cab103 in
Wheelbase77 in
Width Over Tires65 in
Length with Bucket on Ground191 in

Bucket

Bucket specifications
Bucket Width67 in
