Terex
Wacker Neuson
WL36
Wheel Loader
27 specifications
1 / 5
Image 1 of 5
Specifications
30 data points
Operating Specifications
| Operating Weight | 13,228 lb |
|---|---|
| Fuel Capacity | 29.1 gal |
| Tire Size | 405/70 R18 |
| Hydraulic System Fluid Capacity | 23.3 gal |
| Static Tipping Weight | 10,538 lb |
| Operating Voltage | 12 V |
| Turning Radius | 175 in |
Engine
| Engine Model | F4M2011 |
|---|---|
| Displacement | 189 in³ |
| Power Measured @ | 2,200 rpm |
| Net Power | 73.5 hp |
| Number of Cylinders | 4 |
Hydraulic System
| Pump Flow Capacity | 19.0 gal/min |
|---|---|
| Relief Valve Setting | 3,625 psi |
| Pump Type | proportional hydraulic valvve with 3 control circuits and high-speed valve for dumping |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 109 in |
| Wheelbase | 88 in |
| Width Over Tires | 73 in |
| Reach at Max Lift and Dump | 29 in |
| Length with Bucket on Ground | 210 in |
| Hinge Pin - Max Height | 133 in |
Transmission
| Max Speed - Forward | 12.5 mph |
|---|---|
| Max Speed - Reverse | 12.5 mph |
| Transmission Type | Hydrostatic |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Bucket
| Bucket Capacity - heaped | 1.40 yd³ |
|---|---|
| Dump Clearance at Max Raise | 104 in |
| Bucket Width | 77 in |
