Terex
Hitachi
LX80-7
Wheel Loader
40 specifications
1 / 5
Image 1 of 5
Specifications
33 data points
Operating Specifications
| Operating Weight | 29,767 lb |
|---|---|
| Fuel Capacity | 55.5 gal |
| Tire Size | 20.5-25 SGLD/L2 12 PR |
| Hydraulic System Fluid Capacity | 45.0 gal |
| Static Tipping Weight | 19,610 lb |
| Operating Voltage | 24 V |
| Turning Radius | 226 in |
| Rear Axle Oscillation | 16 ° |
Engine
| Engine Model | 1106C-E60TA |
|---|---|
| Displacement | 366 in³ |
| Power Measured @ | 2,200 rpm |
| Net Power | 144.0 hp |
| Number of Cylinders | 6 |
| Aspiration | turbocharged |
Hydraulic System
| Pump Flow Capacity | 41.3 gal/min |
|---|---|
| Relief Valve Setting | 3,625 psi |
| Pump Type | axial piston |
Dimensions
| Ground Clearance | 25 in |
|---|---|
| Height - Top of Cab | 122 in |
| Wheelbase | 115 in |
| Width Over Tires | 94 in |
| Reach at Max Lift and Dump | 47 in |
| Length with Bucket on Ground | 271 in |
| Hinge Pin - Max Height | 158 in |
Transmission
| Max Speed - Forward | 24.9 mph |
|---|---|
| Max Speed - Reverse | 24.9 mph |
| Transmission Type | hydrostatic |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Bucket
| Bucket Capacity - heaped | 3.00 yd³ |
|---|---|
| Dump Clearance at Max Raise | 119 in |
| Breakout Force | 24,425 lb |
| Bucket Width | 100 in |
