Terex
Holland Lift
Q135EL24
Aerial Lift
19 specifications
1 / 5
Image 1 of 5
Specifications
18 data points
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Wheelbase | 91 in |
| Overall Length | 268 in |
| Overall Width | 91 in |
| Gradeability | 45.0 % |
Performance
| Operating Weight | 24,141 lb |
|---|---|
| Max Speed | 3.0 mph |
| Tire Size | 14 x 17.5 |
| Hydraulic System Fluid Capacity | 29.1 gal |
| Fuel Capacity | 29.1 gal |
Platform
| Max Platform Height | 721 in |
|---|---|
| Max Platform Weight Capacity | 500 lb |
| Platform Inner Length | 36 in |
| Platform Inner Width | 71 in |
| Max Working Height | 800 in |
| Max Horizontal Reach | 406 in |
| Platform Rotation | 180 ° |
| Overall height (stowed, guardrail folded) | 102,362 in |
