TerexTerex
TL450
Wheel Loader
14 specifications
1 / 5
Image 1 of 5
Specifications
35 data points
Operating Specifications
| Operating Weight | 8,598 lb |
|---|---|
| Fuel Capacity | 19.9 gal |
| Tire Size | 12 x 16.5 EM 14 |
| Hydraulic System Fluid Capacity | 13.0 gal |
| Static Tipping Weight | 6,063 lb |
| Operating Voltage | 12 V |
| Turning Radius | 152 in |
| Rear Axle Oscillation | 24 ° |
| Rated Bucket Capacity | 0.65 – 1.29 yd³ |
Engine
| Engine Model | F4M 2011 |
|---|---|
| Displacement | 189 in³ |
| Power Measured @ | 2,300 rpm |
| Net Power | 50.0 hp |
| Number of Cylinders | 4 |
| Aspiration | natural |
| Make | Deutz |
Weights
| Operating Weight | 8,598 lb |
|---|
Hydraulic System
| Pump Flow Capacity | 11.0 gal/min |
|---|---|
| Relief Valve Setting | 3,625 psi |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Height - Top of Cab | 97 in |
| Wheelbase | 77 in |
| Width Over Tires | 66 in |
| Reach at Max Lift and Dump | 24 in |
| Length with Bucket on Ground | 189 in |
| Hinge Pin - Max Height | 124 in |
Transmission
| Max Speed - Forward | 11.0 mph |
|---|---|
| Max Speed - Reverse | 11.0 mph |
| Transmission Type | hydrostatic |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Bucket
| Bucket Capacity - heaped | 0.99 yd³ |
|---|---|
| Dump Clearance at Max Raise | 100 in |
| Breakout Force | 8,325 lb |
| Bucket Width | 67 in |
