Terex
Caterpillar
434E
Backhoe Loader
37 specifications
1 / 5
Image 1 of 5
Specifications
44 data points
Operating Specifications
| Operating Weight | 15,895 lb |
|---|---|
| Fuel Capacity | 30.8 gal |
| Hydraulic System Fluid Capacity | 24.4 gal |
| Cooling System Fluid Capacity | 4.3 gal |
| Tire Size Front - 2wd / 4wd | 12.5 x 18 |
| Operating Voltage | 12 V |
| Oil System Fluid Capacity | 2.3 gal |
| Alternator Supplied Amperage | 120 A |
| Transmission Fluid Capacity | 4.0 gal |
| Max Weight | 18,106 lb |
| Rear Axle Fluid Capacity | 4.1 gal |
| Front Axle Fluid Capacity | 2.6 gal |
Engine
| Displacement | 269 in³ |
|---|---|
| Power Measured @ | 2,200 rpm |
| Gross Power | 93.8 hp |
| Net Power | 88.1 hp |
| Number of Cylinders | 4 |
| Torque Measured @ | 1,400 rpm |
| Engine Make | Deutz |
| Net Max Torque | 295 lb-ft |
| Net Torque Rise | 0 |
Hydraulic System
| Pump Flow Capacity | 21.0 gal/min |
|---|---|
| Relief Valve Pressure | 3,625 psi |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Wheelbase | 84 in |
| Transport Width | 91 in |
| Transport Length | 236 in |
| Height to Top of Suspended Cab | 108 in |
Transmission
| Max Speed | 25.2 mph |
|---|---|
| Max Speed - Reverse | 25.1 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Tires & Wheels
| Rear Tires Size | 19.5 x 24 |
|---|
Backhoe
| Reach From Swivel | 226 in |
|---|---|
| Dig Depth - Extended | 212 in |
| Reach From Swivel - Extended | 263 in |
| Reach at Load Height - Extended | 124 in |
Loader
| Bucket Capacity | 0.20 yd³ |
|---|---|
| Clearance at Max Dump Height | 113 in |
| Bucket Breakout Force | 10,485 lb |
| Bucket Width | 12 in |
| Reach at Max Dump Height | 29 in |
| Dig Depth | 6 in |
Travel Speed
| 4th Gear Fwd | 25.6 mph |
|---|
