434E
Backhoe Loader
37 specifications
1 / 5
Image 1 of 5
Specifications
58 data points
Operating Specifications
| Operating Weight | 16,788 lb |
|---|---|
| Fuel Capacity | 37.0 gal |
| Hydraulic System Fluid Capacity | 18.5 gal |
| Cooling System Fluid Capacity | 4.5 gal |
| Tire Size Front - 2wd / 4wd | 12 * 16.5 |
| Operating Voltage | 12 V |
| Oil System Fluid Capacity | 2.2 gal |
| Alternator Supplied Amperage | 95 A |
| Transmission Fluid Capacity | 5.3 gal |
| Max Weight | 16,788 lb |
| Rear Axle Fluid Capacity | 4.5 gal |
| Front Axle Fluid Capacity | 2.3 gal |
Engine
| Engine Model | TCD 3.6 L4 |
|---|---|
| Displacement | 220 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 74.0 hp |
| Net Power | 69.3 hp |
| Number of Cylinders | 4 |
| Torque Measured @ | 1,300 rpm |
| Engine Make | Deutz |
| Net Max Torque | 288 lb-ft |
| Net Torque Rise | 1 |
Hydraulic System
| Pump Flow Capacity | 21.7 gal/min |
|---|---|
| Relief Valve Pressure | 3,625 psi |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Wheelbase | 84 in |
| Transport Width | 91 in |
| Transport Length | 236 in |
| Height to Top of Suspended Cab | 108 in |
Transmission
| Max Speed | 24.0 mph |
|---|---|
| Max Speed - Reverse | 23.7 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Tires & Wheels
| Rear Tires Size | 19.5 * 24 |
|---|
General Specifications
| Operating Weight lbs (kg) | 16,788 (7,615) — Starting 2016 Model Year |
|---|---|
| Max Digging Depth ft. (m) | 14.8 (4.5) — Starting 2016 Model Year |
| Backhoe Loading Height ft. (m) | 11.5 (3.5) — Starting 2016 Model Year |
| Travel Speed 4th Gear Fwd MPH (kmh) | 24 (38) — Starting 2016 Model Year |
| Loader SAE HP (kw) | 74 (55) — Starting 2016 Model Year |
| Loader Lift Capacity lbs. (kg) | 7,291 (3,307) — Starting 2016 Model Year |
| Loader Breakout Force lbs. (kg) | 9,441 (4,282) — Starting 2016 Model Year |
Backhoe
| Max Digging Depth | 178 in |
|---|---|
| Dig Depth | 197 in |
| Reach From Swivel | 226 in |
| Dig Depth - Extended | 217 in |
| Load Height - Extended | 163 in |
| Reach From Swivel - Extended | 264 in |
| Reach at Load Height - Extended | 124 in |
| Loading Height | 138 in |
Loader
| Bucket Capacity | 0.99 yd³ |
|---|---|
| Lift Capacity | 7,291 lb |
| Clearance at Max Dump Height | 108 in |
| Bucket Breakout Force | 9,441 lb |
| Reach at Max Dump Height | 31 in |
| Dig Depth | 7 in |
| SAE - Net | 74.0 hp |
| Breakout Force | — |
Travel Speed
| 4th Gear Fwd | 24.0 mph |
|---|
