Terex
Caterpillar
434E
Backhoe Loader
37 specifications
1 / 5
Image 1 of 5
Specifications
46 data points
Operating Specifications
| Operating Weight | 17,663 lb |
|---|---|
| Fuel Capacity | 34.4 gal |
| Hydraulic System Fluid Capacity | 37.8 gal |
| Cooling System Fluid Capacity | 4.3 gal |
| Tire Size Front - 2wd / 4wd | 16.9x24 |
| Operating Voltage | 12 V |
| Oil System Fluid Capacity | 2.3 gal |
| Alternator Supplied Amperage | 100 A |
| Turning Radius | 226 in |
| Transmission Fluid Capacity | 6.1 gal |
| Max Weight | 17,663 lb |
| Rear Axle Fluid Capacity | 4.7 gal |
| Front Axle Fluid Capacity | 3.4 gal |
Engine
| Engine Model | 1104C-44TH |
|---|---|
| Displacement | 269 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 100.0 hp |
| Net Power | 94.0 hp |
| Aspiration | Turbo |
| Torque Measured @ | 1,400 rpm |
| Net Max Torque | 290 lb-ft |
Hydraulic System
| Pump Flow Capacity | 21.2 gal/min |
|---|---|
| Relief Valve Pressure | 3,250 psi |
| Pump Type | twin gear |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Wheelbase | 83 in |
| Transport Width | 91 in |
| Transport Length | 288 in |
| Height to Top of Suspended Cab | 110 in |
Transmission
| Max Speed | 25.8 mph |
|---|---|
| Max Speed - Reverse | 7.9 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 2 |
| Transmission Type | Dana transmission full powershift |
Tires & Wheels
| Rear Tires Size | 16.9x24 |
|---|
Backhoe
| Reach From Swivel | 238 in |
|---|---|
| Dig Depth - Extended | 245 in |
| Load Height - Extended | 175 in |
| Reach From Swivel - Extended | 289 in |
| Reach at Load Height - Extended | 120 in |
Loader
| Bucket Capacity | 1.40 yd³ |
|---|---|
| Clearance at Max Dump Height | 106 in |
| Bucket Breakout Force | 12,291 lb |
| Bucket Width | 91 in |
| Reach at Max Dump Height | 26 in |
| Dig Depth | 5 in |
