Terex
TXL160-1
- Operating Weight
- 18,960 lb
- Bucket Capacity - heaped
- 2.11 yd³
- Gross Power
- 99.0 hp
- Net Power
- 90.0 hp
1 / 5
Image 1 of 5
Specifications
43 data points
Operating Specifications
| Operating Weight | 18,960 lb |
|---|---|
| Fuel Capacity | 48.9 gal |
| Tire Size | 17.5-25 |
| Hydraulic System Fluid Capacity | 26.5 gal |
| Static Tipping Weight | 14,330 lb |
| Operating Voltage | 24 V |
| Turning Radius | 212 in |
| Engine Oil Fluid Capacity | 3.5 gal |
| Rear Axle Oscillation | 22 ° |
| Alternator Supplied Amperage | 65 A |
| Front Axle/Diff Fluid Capacity | 4.8 gal |
| Rear Axle/Diff Fluid Capacity | 4.8 gal |
| Cooling System Fluid Capacity | 7.7 gal |
| Transmission Fluid Capacity | 5.3 gal |
Engine
| Engine Model | DB58S |
|---|---|
| Displacement | 353 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 99.0 hp |
| Net Power | 90.0 hp |
| Number of Cylinders | 6 |
| Aspiration | natural |
| Torque Measured @ | 1,600 rpm |
Hydraulic System
| Pump Flow Capacity | 32.0 gal/min |
|---|---|
| Raise Time | 6.0 s |
| Lower Time | 3.1 s |
| Dump Time | 1.5 s |
| Relief Valve Setting | 2,845 psi |
| Pump Type | gear type |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 126 in |
| Wheelbase | 107 in |
| Reach at Max Lift and Dump | 41 in |
| Length with Bucket on Ground | 258 in |
| Hinge Pin - Max Height | 143 in |
Transmission
| Max Speed - Forward | 21.5 mph |
|---|---|
| Max Speed - Reverse | 14.0 mph |
| Transmission Type | full auto powershift countershaft |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 2.11 yd³ |
|---|---|
| Dump Clearance at Max Raise | 109 in |
| Breakout Force | 17,200 lb |
| Bucket Width | 97 in |
