Terex
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
42 data points
Operating Specifications
| Operating Weight | 30,420 lb |
|---|---|
| Fuel Capacity | 71.4 gal |
| Tire Size | 20.5x25x16PR |
| Hydraulic System Fluid Capacity | 51.6 gal |
| Static Tipping Weight | 26,456 lb |
| Operating Voltage | 24 V |
| Turning Radius | 239 in |
| Engine Oil Fluid Capacity | 5.6 gal |
| Rear Axle Oscillation | 22 ° |
| Alternator Supplied Amperage | 65 A |
| Front Axle/Diff Fluid Capacity | 7.3 gal |
| Rear Axle/Diff Fluid Capacity | 7.3 gal |
| Cooling System Fluid Capacity | 13.3 gal |
| Transmission Fluid Capacity | 9.3 gal |
Engine
| Engine Model | DB58Tis |
|---|---|
| Displacement | 353 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 163.0 hp |
| Number of Cylinders | 6 |
| Aspiration | turbocharged |
| Torque Measured @ | 1,300 rpm |
Hydraulic System
| Pump Flow Capacity | 66.0 gal/min |
|---|---|
| Raise Time | 5.3 s |
| Lower Time | 3.3 s |
| Dump Time | 1.2 s |
| Relief Valve Setting | 2,845 psi |
| Pump Type | vane type |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 131 in |
| Wheelbase | 120 in |
| Reach at Max Lift and Dump | 46 in |
| Length with Bucket on Ground | 296 in |
| Hinge Pin - Max Height | 154 in |
Transmission
| Max Speed - Forward | 23.0 mph |
|---|---|
| Max Speed - Reverse | 14.7 mph |
| Transmission Type | full auto powershift countershaft |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 3.20 yd³ |
|---|---|
| Dump Clearance at Max Raise | 109 in |
| Breakout Force | 29,100 lb |
| Bucket Width | 108 in |
