Thomas
Mustang
2026
Skid Steer Loader
31 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 6,600 lb |
|---|---|
| Max Speed | 7.1 mph |
| Fuel Capacity | 19.3 gal |
| Hydraulic System Fluid Capacity | 14.8 gal |
| Tire Size | 10.00x16.5 |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 40 A |
Engine
| Engine Model | V2203E |
|---|---|
| Displacement | 134 in³ |
| Power Measured @ | 2,800 rpm |
| Gross Power | 50.0 hp |
| Number of Cylinders | 4 |
Hydraulic System
| Pump Flow Capacity | 16.6 gal/min |
|---|---|
| Relief Valve Pressure | 5,000 psi |
Dimensions
| Ground Clearance | 7 in |
|---|---|
| Height - Top of Cab | 84 in |
| Wheelbase | 40 in |
| Width Over Tires | 65 in |
| Reach at Max Lift and Dump | 21 in |
| Length with Bucket | 141 in |
| Clearance at Max Lift and Dump | 111 in |
| Turning Radius from Center - inc bucket | 41 in |
| Turning Radius from Center - machine rear | 33 in |
| Length w/o Bucket | 110 in |
Loader
| Operating Load Rating | 1,700 lb |
|---|---|
| Breakout Force | 4,000 psi |
