Thomas

75

Excavator

Operating Weight
16,425 lb
Max Digging Depth
167 in
Net Power
59.0 hp
All excavators
Thomas 75 Excavator
1 / 5
Image 1 of 5
Image: deere.com

Specifications

20 data points

Operating Specifications

Operating Specifications specifications
Operating Weight16,425 lb
Fuel Capacity34.4 gal
Hydraulic Pump Flow Capacity53.7 gal/min
Hydraulic System Relief Valve Pressure10,800 psi

Engine

Engine specifications
Engine ModelV3300
Displacement203 in³
Power Measured @2,300 rpm
Net Power59.0 hp

Dimensions

Dimensions specifications
Height - Top of Cab101 in
Tail Swing Radius62 in
Width to Outside of Tracks85 in

Undercarriage

Undercarriage specifications
Track Gauge67 in
Max Travel Speed3.3 mph
Shoe Size18 in

Boom/Stick Excavator Option 1

Boom/Stick Excavator Option 1 specifications
Max Digging Depth167 in
Max Loading Height182 in
Max Vertical Wall Digging Depth138 in
Max Cutting Height263 in
Shipping Length of Unit248 in

Swing Mechanism

Swing Mechanism specifications
Swing Speed10 rpm
