Tigercat
John Deere
437C
Log Loader
20 specifications
1 / 5
Image 1 of 5
Specifications
14 data points
Operating Specifications
| Operating Weight | 36,300 lb |
|---|---|
| Fuel Capacity | 79.3 gal |
| Hydraulic System Fluid Capacity | 64.8 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 80 A |
Engine
| Engine Model | QSB6.7 Tier III |
|---|---|
| Net Power | 205.0 hp |
Hydraulic System
| Pump Type | Load sensing |
|---|
Dimensions
| Overall Width | 102 in |
|---|---|
| Tail Swing Radius | 110 in |
Swing Mechanism
| Swing Speed | 9 rpm |
|---|
Boom/Stick Log Loader Option 1
| Max Height | 300 in |
|---|---|
| Max Reach at Ground Level | 384 in |
| Boom/Stick Option (LGL) 1 | boom |
