Tigercat
Caterpillar
570
Processor
18 specifications
1 / 5
Image 1 of 5
Specifications
11 data points
Operating Specifications
| Operating Weight | 56,100 lb |
|---|---|
| Fuel Capacity | 79.3 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 80 A |
Engine
| Engine Model | QSB6.7 Tier III |
|---|---|
| Power Measured @ | 1,800 rpm |
| Gross Power | 205.0 hp |
Dimensions
| Height - Top of Cab | 143 in |
|---|---|
| Overall Width | 135 in |
Undercarriage
| Ground Clearance | 30 in |
|---|
Boom
| Max Reach w/ Head | 384 in |
|---|
Comparable machines
Other processors/harvesters in a similar weight class.
