Toyota
Komatsu
FG25T-12
Forklift
32 specifications
1 / 5
Image 1 of 5
Specifications
29 data points
Operating Specifications
| Operating Weight | 12,570 lb |
|---|---|
| Max Speed | 10.9 mph |
| Number of Front Wheels | 2 |
| Number of Rear Wheels | 2 |
| Tire Type | cushion |
| Drawbar Pull | 3,650 lb |
| Hydraulic System Relief Valve Pressure | 2,630 psi |
| Tire Size | Front - 22 x 12 x 16 Rear - 18 x 7 x 12-1/8 |
Engine
| Fuel Type | Electric |
|---|
Dimensions
| Wheelbase | 62 in |
|---|---|
| Overall Width | 54 in |
| Turning Radius | 88 in |
| Length to Fork Face | 104 in |
| Gradeability | 13.0 % |
| Height to Top of Overhead Guard | 91 in |
| Max Fork Height | 121 in |
| Right Angle Stack | 107 in |
| Front Wheel Tread Width | 41 in |
| Rear Wheel tread Width - max | 43 in |
| Free lift | 4 in |
Mast
| Load Capacity | 10,000 lb |
|---|---|
| Load Center | 24 in |
| Lift Speed | 0.6 mph |
| Lower Speed | 1.1 mph |
Electrical System
| Battery capacity | — |
|---|---|
| Battery voltage | 36 V/Ah |
| Control Drive | Transistor Invertor |
| Control Power Steering | Transistor Chopper |
| Battery | 48 |
