Toyota
Komatsu
FG25T-12
Forklift
32 specifications
1 / 5
Image 1 of 5
Specifications
29 data points
Operating Specifications
| Operating Weight | 6,960 lb |
|---|---|
| Max Speed | 11.5 mph |
| Number of Front Wheels | 2 |
| Number of Rear Wheels | 2 |
| Tire Type | cushion |
| Drawbar Pull | 3,290 lb |
| Hydraulic System Relief Valve Pressure | 2,580 psi |
| Tire Size | Front - 21 x 7 x 15 Rear - 16 x 5 x 10.5 |
Engine
| Power | 48.0 hp |
|---|---|
| Fuel Type | Electric |
Dimensions
| Wheelbase | 52 in |
|---|---|
| Overall Width | 42 in |
| Turning Radius | 72 in |
| Overall Height - mast lowered | 84 in |
| Length to Fork Face | 83 in |
| Gradeability | 21.0 % |
| Height to Top of Overhead Guard | 89 in |
| Max Fork Height | 132 in |
| Right Angle Stack | 88 in |
| Front Wheel Tread Width | 35 in |
| Rear Wheel tread Width - max | 36 in |
| Free lift | 6 in |
Mast
| Load Capacity | 5,000 lb |
|---|---|
| Lift Speed | 0.9 mph |
| Lower Speed | 1.1 mph |
Electrical System
| Battery capacity | 765 Ah |
|---|---|
| Battery voltage | 48 V |
| Control Drive | Transistor Invertor |
| Control Power Steering | Transistor Invertor |
