Toyota
Hyster
H110FT
Forklift
38 specifications
1 / 5
Image 1 of 5
Specifications
45 data points
Operating Specifications
| Operating Weight | 14,573 lb |
|---|---|
| Number of Front Wheels | 2 |
| Number of Rear Wheels | 2 |
| Tire Type | Pneumatic |
| Drawbar Pull | 7,937 lb |
| Fuel Capacity | 31.8 gal |
Engine
| Engine Model | 1FS |
|---|---|
| Displacement | 224 in³ |
| Power Measured @ | 2,350 rpm |
| Number of Cylinders | 4 |
| Torque Measured @ | 1,600 rpm |
| Engine Make | TOYOTA |
| Power | 87.0 hp |
| Fuel Type | Gasoline |
| Torque | 200 lb-ft |
| Battery | 12 V |
Hydraulic System
| Main pump flow standard | 33.9 gal/min |
|---|---|
| Maximum operating pressure | 2,630 psi |
Dimensions
| Ground Clearance | 5 in |
|---|---|
| Wheelbase | 79 in |
| Overall Width | 57 in |
| Turning Radius | 109 in |
| Overall Height - mast lowered | 88 in |
| Length to Fork Face | 124 in |
| Gradeability | 34.0 % |
| Height to Top of Overhead Guard | 91 in |
| Max Fork Height | 121 in |
| Right Angle Stack | 131 in |
| Free lift | 4 in |
Transmission
| Max Speed - Forward | 13.7 mph |
|---|---|
| Max Speed - Reverse | 13.7 mph |
| Transmission Type | Powershift |
| Travelspeeds(BACKWRD)Speed range | 1 |
| Travelspeeds(FRWD)Speed range | 1 |
Brakes & Steering
| Service brake | Hydraulic |
|---|---|
| Parking brake | Hand |
Tires & Wheels
| Standard_Option_Front | — |
|---|---|
| Standard_Rear | 7.00-12-12PR |
Mast
| Load Capacity | 9,921 lb |
|---|---|
| Load Center | 24 in |
| Lift Speed | 1.1 mph |
| Mast Tip Forward | 6 ° |
| Mast Tip Rear | 12 ° |
| Lower Speed | 1.2 mph |
| Max Fork Spread | 46 in |
