Toyota
Komatsu
FG25T-12
Forklift
32 specifications
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight | 8,003 lb |
|---|---|
| Max Speed | 10.6 mph |
| Number of Front Wheels | 2 |
| Number of Rear Wheels | 2 |
| Tire Type | Cushion |
| Fuel Capacity | 11.9 gal |
| Hydraulic System Relief Valve Pressure | 2,275 psi |
| Hydraulic System Fluid Capacity | 20.0 gal |
Engine
| Engine Model | 4Y-ECS |
|---|---|
| Displacement | 136 in³ |
| Power Measured @ | 2,570 rpm |
| Number of Cylinders | 4 |
| Torque Measured @ | 2,100 rpm |
| Engine Make | TOYOTA |
| Power | 51.0 hp |
| Torque | 118 lb-ft |
Dimensions
| Overall Width | 42 in |
|---|---|
| Turning Radius | 78 in |
| Length to Fork Face | 95 in |
| Height to Top of Overhead Guard | 81 in |
Mast
| Load Capacity | 5,000 lb |
|---|---|
| Load Center | 24 in |
| Lift Speed | 1.4 mph |
Performance
| Drawbar Pull Max -Full Load | 40,786 lb |
|---|---|
| Drawbar Pull Max -No Load | 17,196 lb |
