Toyota
Komatsu
FG25T-12
Forklift
32 specifications
1 / 5
Image 1 of 5
Specifications
38 data points
Operating Specifications
| Operating Weight | 9,281 lb |
|---|---|
| Max Speed | 11.2 mph |
| Number of Front Wheels | 2 |
| Number of Rear Wheels | 2 |
| Tire Type | Pneumatic |
| Drawbar Pull | 4,409 lb |
| Fuel Capacity | 15.9 gal |
Engine
| Engine Model | 4Y - ECS - HP5 |
|---|---|
| Displacement | 136 in³ |
| Power Measured @ | 2,570 rpm |
| Number of Cylinders | 4 |
| Torque Measured @ | 2,200 rpm |
| Engine Make | TOYOTA |
| Power | 57.0 hp |
| Fuel Type | Gasoline |
| Torque | 118 lb-ft |
| Battery | 12 V |
Hydraulic System
| Main pump flow standard | 21.0 gal/min |
|---|---|
| Maximum operating pressure | 2,275 psi |
Dimensions
| Ground Clearance | 5 in |
|---|---|
| Wheelbase | 67 in |
| Overall Width | 49 in |
| Turning Radius | 94 in |
| Overall Height - mast lowered | 86 in |
| Length to Fork Face | 110 in |
| Gradeability | 26.0 % |
| Height to Top of Overhead Guard | 86 in |
| Max Fork Height | 132 in |
| Right Angle Stack | 113 in |
| Free lift | 5 in |
Brakes & Steering
| Service brake | Hydraulic |
|---|---|
| Parking brake | Mechanical |
Tires & Wheels
| Rear Tires Size | 6.50-10-10PR (1) |
|---|---|
| Front Tires Size | 28 x 9-15-12PR (1) |
Mast
| Load Capacity | 6,000 lb |
|---|---|
| Lift Speed | 1.1 mph |
| Lower Speed | 1.1 mph |
| Max Fork Spread | 10 in |
