Mec
2647ES
Aerial Lift
21 specifications
1 / 5
Image 1 of 5
Specifications
20 data points
Engine
| System Voltage | 24 V |
|---|---|
| Battery Amp Hours | 220 |
| Number of Batteries | 4 |
| Charger Amps | 25 |
Dimensions
| Ground Clearance | 4 in |
|---|---|
| Overall Length | 8 in |
| Overall Width | 49 in |
| Height w/ Rails | 89 in |
| Height w/o Rails | 74 in |
Performance
| Operating Weight | 5,481 lb |
|---|---|
| Max Speed | 2.0 mph |
| Tire Size | 381mm dia |
| Tire Fill/Type | solid rubber / non-marking |
Platform
| Max Platform Height | 384 in |
|---|---|
| Max Platform Weight Capacity | 750 lb |
| Platform Inner Length | 126 in |
| Platform Inner Width | 46 in |
| Max Working Height | 466 in |
| Lift Time | 65.0 s |
| Lower Time | 40.0 s |
