Ursus
Fendt
817
Tractor
23 specifications
1 / 5
Image 1 of 5
Specifications
18 data points
Operating Specifications
| Operating Weight | 13,051 lb |
|---|---|
| Fuel Capacity | 93.8 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 14,771 lb |
Engine
| Engine Model | Z 8602.035 M |
|---|---|
| Displacement | 446 in³ |
| Gross Power | 160.0 hp |
| Number of Cylinders | 6 |
| PTO Power | 141.0 hp |
Hydraulic System
| Pump Flow Capacity | 14.6 gal/min |
|---|
Dimensions
| Height - Top of Cab | 121 in |
|---|---|
| Wheelbase | 107 in |
| Overall Length | 17 in |
| Tire Size | front 14.9R28 rear 20.8R38 |
| Width Outside Frame | 96 in |
Transmission
| Max Speed | 20.3 mph |
|---|---|
| Number of Forward Gears | 16 |
| Transmission Type | mechanical with torque amplifier synchromesh |
| Number of Reverse Gears | 8 |
