Ursus
Fendt
817
Tractor
23 specifications
1 / 5
Image 1 of 5
Specifications
27 data points
Operating Specifications
| Operating Weight | 13,625 lb |
|---|---|
| Fuel Capacity | 93.8 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 15,873 lb |
| 3 Point Hitch Type | cat. III |
| Alternator Supplied Amperage | 70 A |
| Operating Voltage | 14 V |
| Cooling System Fluid Capacity | 7.7 gal |
| Hydraulic System Fluid Capacity | 16.7 gal |
| Engine Oil Capacity | 6.4 gal |
Engine
| Engine Model | Z 8604.020 TURBO |
|---|---|
| Displacement | 446 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 190.0 hp |
| Number of Cylinders | 6 |
| Aspiration | turbocharged |
| PTO Power | 161.0 hp |
Hydraulic System
| Pump Flow Capacity | 14.6 gal/min |
|---|---|
| Relief Valve Pressure | 2,321 psi |
Dimensions
| Wheelbase | 107 in |
|---|---|
| Overall Length | 15 in |
| Tire Size | front 16.9R28 rear 20.8R38 |
| Width Outside Frame | 98 in |
Transmission
| Max Speed | 18.3 mph |
|---|---|
| Number of Forward Gears | 16 |
| Transmission Type | mechanical synchromesh |
| Number of Reverse Gears | 8 |
Axles
| Final Drive | rear axle |
|---|
