Valtra
Fendt
817
Tractor
23 specifications
Valtra
Classic N101
- Operating Weight
- 10,692 lb
- Displacement
- 269 in³
- Power Measured @
- 2,200 rpm
- Gross Power
- 114.0 hp
1 / 5
Image 1 of 5
Specifications
20 data points
Operating Specifications
| Operating Weight | 10,692 lb |
|---|---|
| Fuel Capacity | 58.2 gal |
| Turning Radius | 175 in |
Engine
| Engine Model | 44CWA |
|---|---|
| Displacement | 269 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 114.0 hp |
| Net Power | 108.7 hp |
| Number of Cylinders | 4 |
Hydraulic System
| Pump Flow Capacity | 19.3 gal/min |
|---|---|
| Relief Valve Pressure | 2,843 psi |
Dimensions
| Height - Top of Cab | 109 in |
|---|---|
| Wheelbase | 102 in |
| Overall Length | 15 in |
| Tire Size | Front 14.9R24 Rear 18.4R34 |
| Width Outside Frame | 86 in |
Transmission
| Max Speed | 24.9 mph |
|---|---|
| Number of Forward Gears | 24 |
| Transmission Type | Synchro shuttle |
| Number of Reverse Gears | 24 |
