Venieri
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight | 28,660 lb |
|---|---|
| Tire Size | 20.5x25 |
| Static Tipping Weight | 16,535 lb |
| Turning Radius | 230 in |
Engine
| Engine Model | 1106-E60TA |
|---|---|
| Displacement | 366 in³ |
| Net Power | 150.2 hp |
| Number of Cylinders | 6 |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Height - Top of Cab | 125 in |
| Wheelbase | 115 in |
| Width Over Tires | 90 in |
| Reach at Max Lift and Dump | 40 in |
| Length with Bucket on Ground | 268 in |
Transmission
| Max Speed - Forward | 22.4 mph |
|---|---|
| Max Speed - Reverse | 22.4 mph |
| Transmission Type | Hydrostatic |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Bucket Capacity - heaped | 3.30 yd³ |
|---|---|
| Dump Clearance at Max Raise | 118 in |
| Bucket Width | 101 in |
