Venieri
Caterpillar
434E
Backhoe Loader
37 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight 4wd | 18,960 lb |
|---|---|
| Turning Radius | 193 in |
Engine
| Engine Model | 1104-44T |
|---|---|
| Displacement | 269 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 115.4 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
Hydraulic System
| Pump Flow Capacity | 38.4 gal/min |
|---|---|
| Relief Valve Pressure | 3,336 psi |
| Pump Type | Piston |
Dimensions
| Transport Width | 94 in |
|---|---|
| Transport Length | 236 in |
Transmission
| Max Speed | 23.7 mph |
|---|---|
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 2 |
| Transmission Type | Hydrostatic |
Backhoe
| Dig Depth | 236 in |
|---|---|
| Reach From Swivel | 221 in |
| Load Height | 209 in |
Loader
| Bucket Capacity | 1.80 yd³ |
|---|---|
| Clearance at Max Dump Height | 138 in |
| Bucket Width | 93 in |
