Venieri
Caterpillar
434E
Backhoe Loader
37 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight 4wd | 14,330 lb |
|---|---|
| Turning Radius | 178 in |
Engine
| Engine Model | 704-30 |
|---|---|
| Displacement | 238 in³ |
| Power Measured @ | 2,400 rpm |
| Gross Power | 65.8 hp |
| Number of Cylinders | 4 |
Hydraulic System
| Pump Flow Capacity | 21.7 gal/min |
|---|---|
| Relief Valve Pressure | 3,336 psi |
| Pump Type | Piston |
Dimensions
| Transport Width | 76 in |
|---|---|
| Transport Length | 210 in |
Transmission
| Max Speed | 19.9 mph |
|---|---|
| Max Speed - Reverse | 19.9 mph |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
| Transmission Type | Hydrostatic |
Backhoe
| Dig Depth | 162 in |
|---|---|
| Reach From Swivel | 185 in |
| Load Height | 181 in |
Loader
| Bucket Capacity | 0.99 yd³ |
|---|---|
| Clearance at Max Dump Height | 144 in |
| Bucket Width | 73 in |
