Versatile
Mccormick
MTX200
Tractor
19 specifications
Versatile
835
- Operating Weight
- 27,999 lb
- Displacement
- 854 in³
- Power Measured @
- 2,100 rpm
- Gross Power
- 230.0 hp
1 / 5
Image 1 of 5
Specifications
31 data points
Operating Specifications
| Operating Weight | 27,999 lb |
|---|---|
| Fuel Capacity | 185.0 gal |
| 3 Point Hitch Type | 4N/3 |
| Alternator Supplied Amperage | 90 A |
| Cooling System Fluid Capacity | 11.5 gal |
| Hydraulic System Fluid Capacity | 21.0 gal |
| Engine Oil Capacity | 10.5 gal |
| Front Tire Size | 20.8x38 |
| Rear Tire Size | 20.8x38 |
Engine
| Engine Model | NT-855-A230 |
|---|---|
| Displacement | 854 in³ |
| Power Measured @ | 2,100 rpm |
| Gross Power | 230.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged |
| Engine Make | Cummins |
| PTO Power | 198.0 hp |
| Stroke | 6 in |
| Bore | 6 in |
Hydraulic System
| Pump Flow Capacity | 23.6 gal/min |
|---|---|
| Number of Remote Control Valves | 4 |
| Relief Valve Pressure | 2,250 psi |
| Hydraulic System Type | Open center |
Dimensions
| Height - Top of Cab | 127 in |
|---|---|
| Wheelbase | 130 in |
| Overall Length | 253 in |
| Width Outside Frame | 143 in |
Transmission
| Max Speed - Reverse | 5.3 mph |
|---|---|
| Max Speed - Forward | 14.3 mph |
| Number of Forward Gears | 12 |
| Number of Reverse Gears | 4 |
