BOMAG
BW 191 ADO-5
Smooth Drum Roller
35 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight | 31,306 lb |
|---|---|
| Max Speed | 7.1 mph |
| Fuel Capacity | 104.9 gal |
| Operating Width | 89 in |
Engine
| Engine Model | 6BT5.9C |
|---|---|
| Displacement | 359 in³ |
| Power Measured @ | 2,300 rpm |
| Gross Power | 185.1 hp |
| Aspiration | turbocharged |
| Make | Cummins |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 128 in |
| Wheelbase | 10 in |
| Overall Length | 19 in |
| Turning Radius - Inside | 142 in |
Tires & Wheels
| Tires | 23.1x20-26 8PR |
|---|
Drum
| Drum Width | 83 in |
|---|---|
| Drum Diameter | 59 in |
| Vibration Frequency 1 | 29 vpm |
| Vibration Frequency 2 | 35 vpm |
| Static Linear Load | 17 lb-ft |
| Vibration Frequency | — |
| Nominal Amplitude - Med | 0 in |
