Vibromax

1805PD

Walk-Behind Compactor

Operating Weight
41,006 lb
Max Speed
7.4 mph
Drum Width
83 in
Gross Power
185.1 hp
All walk/tow behind compactors
Vibromax 1805PD Walk-Behind Compactor
1 / 5
Image 1 of 5
Image: max-machinery.en.made-in-china.com

Specifications

25 data points

Operating Specifications

Operating Specifications specifications
Operating Weight41,006 lb
Max Speed7.4 mph
Operating Width89 in
Fuel Capacity104.9 gal

Engine

Engine specifications
Engine Model6BT5.9C
Displacement359 in³
Gross Power185.1 hp
Aspirationturbocharged
MakeCummins

Dimensions

Dimensions specifications
Ground Clearance18 in
Height - Top of Cab128 in
Wheelbase10 in
Turning Radius - Inside142 in
Overall Length w/o Blade233 in

Tires & Wheels

Tires & Wheels specifications
Tires23.1x20-26 8PR

Drum

Drum specifications
Drum Width83 in
Drum Diameter55 in
Centrifugal Force - High46,086 lb
Nominal Amplitude - High0 in
Vibration Frequency 129 vpm
Vibration Frequency—
Vibratory Frequency 235 vpm
Number of Pads132
Pad Surface Area24 in³
Pad Height4 in
