Bitelli
RG248
Smooth Drum Roller
22 specifications
1 / 5
Image 1 of 5
Specifications
29 data points
Operating Specifications
| Operating Weight | 43,431 lb |
|---|---|
| Max Speed | 7.4 mph |
| Fuel Capacity | 84.6 gal |
| Operating Width | 89 in |
| Operating Voltage | 12 V |
| Hydraulic System Fluid Capacity | 21.2 gal |
| Engine Oil Capacity | 3.9 gal |
| Alternator Supplied Amperage | 95 A |
| Cooling System Fluid Capacity | 5.1 gal |
Engine
| Engine Model | B 5.9-173 C |
|---|---|
| Displacement | 359 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 173.0 hp |
| Number of Cylinders | 6 |
| Aspiration | turbocharged |
| Make | Cummins |
Dimensions
| Ground Clearance | 20 in |
|---|---|
| Height - Top of Cab | 118 in |
| Wheelbase | 10 in |
| Overall Length | 20 in |
| Turning Radius - Inside | 142 in |
Tires & Wheels
| Tires | 23.1-26/8PR AWT |
|---|
Drum
| Drum Width | 83 in |
|---|---|
| Drum Diameter | 63 in |
| Vibration Frequency 1 | 29 vpm |
| Vibration Frequency 2 | 35 vpm |
| Static Linear Load | 26 lb-ft |
| Vibration Frequency | — |
| Nominal Amplitude - Med | 0 in |
