Hypac
C812D
Padfoot Compactor
27 specifications
1 / 5
Image 1 of 5
Specifications
31 data points
Operating Specifications
| Operating Weight | 10,803 lb |
|---|---|
| Max Speed | 7.9 mph |
| Fuel Capacity | 47.6 gal |
| Operating Width | 60 in |
| Hydraulic System Fluid Capacity | 15.9 gal |
| Operating Voltage | 12 V |
| Engine Oil Capacity | 2.2 gal |
| Alternator Supplied Amperage | 60 A |
| Cooling System Fluid Capacity | 3.7 gal |
Engine
| Engine Model | B 3.3 |
|---|---|
| Displacement | 199 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 60.4 hp |
| Number of Cylinders | 4 |
| Make | Cummins |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 104 in |
| Wheelbase | 7 in |
| Overall Length | 14 in |
| Width Over Tires | 60 in |
| Turning Radius - Inside | 122 in |
| Overall Length w/o Blade | 173 in |
Drum
| Vibration Frequency 1 | 32 vpm |
|---|---|
| Centrifugal Force - High | 22,841 lb |
| Nominal Amplitude - High | 0 in |
| Pad Height | 3 in |
| Number of Pads | 77 |
| Vibration Frequency | 1,920 vpm |
| Static Linear Load | 7 lb-ft |
| Nominal Amplitude - Med | 0 in |
| Centrifugal Force - MEd | 22,841 lb |
