Vogele
Dynapac
F5CS
Asphalt Paver
17 specifications
Vogele
SUPER 1100-2
- Operating Weight w/ Screed
- 18,739 lb
- Paving Width - max
- 166 in
- Gross Power
- 77.8 hp
- Length w/ Screed
- 196 in
1 / 5
Image 1 of 5
Specifications
19 data points
Operating Specifications
| Operating Weight w/ Screed | 18,739 lb |
|---|---|
| Fuel Capacity | 31.8 gal |
| Operating Voltage | 24 V |
Engine
| Engine Model | TCD2011L04w |
|---|---|
| Power Measured @ | 2,300 rpm |
| Gross Power | 77.8 hp |
| Number of Cylinders | 4 |
| Make | Deutz |
Dimensions
| Length of Track on Ground | 79 in |
|---|---|
| Transport Height | 119 in |
| Track Width | 10 in |
| Length w/ Screed | 196 in |
| Width w/ Hopper Open | 131 in |
Hopper/Paver
| Paving Width - max | 166 in |
|---|---|
| Paving Speed - max | 1.1 mph |
| Hopper Capacity | 11 lb |
| Travel Speed - max | 2.3 mph |
| Auger Diameter | 12 in |
| Paving Thickness - max | 8 in |
