Vogele
Dynapac
F5CS
Asphalt Paver
17 specifications
Vogele
SUPER 800
- Operating Weight w/ Screed
- 13,448 lb
- Paving Width - max
- 126 in
- Gross Power
- 60.4 hp
- Length w/ Screed
- 173 in
1 / 5
Image 1 of 5
Specifications
17 data points
Operating Specifications
| Operating Weight w/ Screed | 13,448 lb |
|---|---|
| Fuel Capacity | 19.9 gal |
| Operating Voltage | 24 V |
Engine
| Engine Model | TCD 2011 L03 |
|---|---|
| Power Measured @ | 2,300 rpm |
| Gross Power | 60.4 hp |
| Make | Deutz |
Dimensions
| Length of Track on Ground | 60 in |
|---|---|
| Transport Height | 81 in |
| Track Width | 7 in |
| Length w/ Screed | 173 in |
| Width w/ Hopper Open | 114 in |
Hopper/Paver
| Paving Width - max | 126 in |
|---|---|
| Paving Speed - max | 2.2 mph |
| Hopper Capacity | 5 lb |
| Auger Diameter | 12 in |
| Paving Thickness - max | 8 in |
