VolvoEuclid
R85B
Off-Highway Truck
39 specifications
1 / 5
Image 1 of 5
Specifications
57 data points
Engine
| Engine Model | D16J |
|---|---|
| Displacement | 982 in³ |
| Make | Volvo |
| Net Torque | 2,170 lb-ft |
| Gross Torque | 2,183 lb-ft |
| Horsepower per SAE J1349 Net | 626.0 hp |
| Horsepower, Gross-SAE J1995 | 630.0 hp |
| Max Engine Speed | 1,800 rpm |
Weights
| Operating Weight | 217,700 lb |
|---|---|
| Total Operating Weight | 217,707 lb |
Hydraulic System
| Maximum system pressure | 4,061 psi |
|---|
Dimensions
| Ground Clearance | 28 in |
|---|---|
| Wheelbase | 131 in |
| Overall Length | 482 in |
| Overall Width | 250 in |
| Overall Height | 152 in |
| Dump Height | 315 in |
| Dump Ground Clearance | 41 in |
Transmission
| Max Speed | 34.2 mph |
|---|---|
| Transmission Type | Auto |
| Number of Forward Gears | 6 |
| Number of Reverse Gears | 2 |
Fluid Capacities
| Fuel Tank | 198.2 gal |
|---|---|
| Cooling system | 19.9 gal |
| Hydraulic Tank | 52.4 gal |
| Transmission | 15.4 gal |
| DEF Tank | 15.9 gal |
| Dropbox | 3.2 gal |
| Brake cooling system | 34.7 gal |
| Crankcase | 14.6 gal |
General Specifications
| Operating Weight lbs (kg) | 217,700 (98,750) Starting 2019 Model Year |
|---|---|
| Engine type | Volvo D16J Starting 2019 Model Year |
| Articulated/Rigid | Articulated Starting 2024 Model Year |
| Drive Configuration | 6x4 and 6x6 Starting 2019 Model Year |
| Rated Payload Tons (Metric Tons) | 60.6 (55) Starting 2019 Model Year |
| Mfg. Model | A60H Starting 2019 Model Year |
| Drive System Mech/Electr. | M Starting 2019 Model Year |
Drive System
| Drive Config | 4x6 and 6x6 |
|---|---|
| Transmission | 6630 ORS |
| Axles | AHW80 |
| Dropbox | IL3 ATC |
| Torque converter | 1.85:1 |
Articulating/Rigid
| Articulating/Rigid | Articulated |
|---|
Dump
| Rated Payload | 133,600 lb |
|---|---|
| Dump Angle | 70 ° |
| Lower Time | 10.0 s |
| Capacity - Heaped | 44.00 yd³ |
| Capacity - Struck | 33.80 yd³ |
Electrical System
| Alternator | — |
|---|---|
| Starter motor | 9 |
| Battery | 2x12 |
| Battery capacity | — |
| Voltage | — |
Body
| Plate thickness-Front | 0 in |
|---|---|
| Plate thickness-Bottom | 1 in |
| Plate thickness-Chute | 1 in |
| Plate thickness-Sides | 1 in |
