Volvo
Caterpillar
434E
Backhoe Loader
37 specifications
1 / 5
Image 1 of 5
Specifications
47 data points
Operating Specifications
| Operating Weight 2wd | 16,125 lb |
|---|---|
| Fuel Capacity | 31.7 gal |
| Hydraulic System Fluid Capacity | 29.1 gal |
| Cooling System Fluid Capacity | 5.0 gal |
| Tire Size Front - 2wd / 4wd | 2wd Goodyear 11Lx16 12 PR Laborer Tread / 4wd 12Lx16.5 |
| Operating Voltage | 12 V |
| Oil System Fluid Capacity | 3.7 gal |
| Alternator Supplied Amperage | 70 A |
| Turning Radius | 125 in |
| Rear Axle Fluid Capacity | 3.7 gal |
| Front Axle Fluid Capacity | 1.7 gal |
Engine
| Engine Model | D4D |
|---|---|
| Displacement | 247 in³ |
| Power Measured @ | 2,200 rpm |
| Net Power | 83.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,500 rpm |
| Net Max Torque | 288 lb-ft |
| Net Torque Rise | 0 |
Hydraulic System
| Pump Flow Capacity | 30.6 gal/min |
|---|---|
| Relief Valve Pressure | 526 psi |
| Pump Type | Open-center flow-sharing with single gear type pump |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Wheelbase | 85 in |
| Transport Width | 93 in |
| Transport Length | 283 in |
| Height to Top of Suspended Cab | 113 in |
Transmission
| Max Speed | 24.1 mph |
|---|---|
| Max Speed - Reverse | 24.1 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
| Transmission Type | Powershuttle gear box |
Tires & Wheels
| Rear Tires Size | 19.5Lx24 |
|---|
Backhoe
| Dig Depth | 169 in |
|---|---|
| Reach From Swivel | 228 in |
| Dig Depth - Extended | 210 in |
| Load Height - Extended | 170 in |
| Reach From Swivel - Extended | 268 in |
| Load Height | 146 in |
Loader
| Bucket Capacity | 1.29 yd³ |
|---|---|
| Lift Capacity | 5,296 lb |
| Clearance at Max Dump Height | 106 in |
| Bucket Breakout Force | 10,003 lb |
| Bucket Width | 93 in |
| Reach at Max Dump Height | 30 in |
| Dig Depth | 7 in |
