Volvo
New Holland
W110B
Wheel Loader
43 specifications
Volvo
BM 4300B
- Operating Weight
- 20,944 lb
- Bucket Capacity - heaped
- 2.00 yd³
- Gross Power
- 118.0 hp
- Net Power
- 110.0 hp
1 / 5
Image 1 of 5
Specifications
44 data points
Operating Specifications
| Operating Weight | 20,944 lb |
|---|---|
| Fuel Capacity | 50.2 gal |
| Tire Size | 17.5R25/12 |
| Hydraulic System Fluid Capacity | 34.4 gal |
| Static Tipping Weight | 14,418 lb |
| Operating Voltage | 24 V |
| Turning Radius | 198 in |
| Engine Oil Fluid Capacity | 3.0 gal |
| Rear Axle Oscillation | 26 ° |
| Alternator Supplied Amperage | 55 A |
| Front Axle/Diff Fluid Capacity | 6.9 gal |
| Rear Axle/Diff Fluid Capacity | 6.9 gal |
| Cooling System Fluid Capacity | 6.1 gal |
| Transmission Fluid Capacity | 7.2 gal |
Engine
| Engine Model | BM TD 45 B |
|---|---|
| Displacement | 273 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 118.0 hp |
| Net Power | 110.0 hp |
| Number of Cylinders | 4 |
| Aspiration | turbocharged |
| Torque Measured @ | 1,400 rpm |
Hydraulic System
| Pump Flow Capacity | 50.2 gal/min |
|---|---|
| Raise Time | 4.8 s |
| Lower Time | 2.9 s |
| Dump Time | 3.3 s |
| Relief Valve Setting | 2,320 psi |
| Pump Type | Vane pump |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 119 in |
| Wheelbase | 107 in |
| Width Over Tires | 91 in |
| Reach at Max Lift and Dump | 41 in |
| Length with Bucket on Ground | 257 in |
| Hinge Pin - Max Height | 144 in |
Transmission
| Max Speed - Forward | 23.0 mph |
|---|---|
| Max Speed - Reverse | 23.0 mph |
| Transmission Type | power-shift |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Bucket Capacity - heaped | 2.00 yd³ |
|---|---|
| Dump Clearance at Max Raise | 113 in |
| Breakout Force | 18,510 lb |
| Bucket Width | 96 in |
