Volvo
Caterpillar
434E
Backhoe Loader
37 specifications
1 / 5
Image 1 of 5
Specifications
32 data points
Operating Specifications
| Fuel Capacity | 25.4 gal |
|---|---|
| Hydraulic System Fluid Capacity | 50.2 gal |
| Cooling System Fluid Capacity | 4.3 gal |
| Tire Size Front - 2wd / 4wd | 14.9-24/14 |
| Operating Voltage | 24 V |
| Oil System Fluid Capacity | 2.8 gal |
| Alternator Supplied Amperage | 43 A |
| Transmission Fluid Capacity | 5.9 gal |
| Max Weight | 21,495 lb |
Engine
| Engine Model | BM TD 42 |
|---|---|
| Displacement | 256 in³ |
| Gross Power | 84.5 hp |
| Number of Cylinders | 4 |
| Net Max Torque | 221 lb-ft |
Hydraulic System
| Pump Flow Capacity | 29.9 gal/min |
|---|---|
| Relief Valve Pressure | 2,465 psi |
| Pump Type | gear pump |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Wheelbase | 101 in |
| Transport Length | 318 in |
| Height to Top of Suspended Cab | 113 in |
Transmission
| Max Speed | 18.5 mph |
|---|---|
| Max Speed - Reverse | 18.5 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
| Transmission Type | hydromechanical gearbox with power shift |
Tires & Wheels
| Rear Tires Size | 18.4-34/14 |
|---|
Backhoe
| Dig Depth | 169 in |
|---|---|
| Reach From Swivel | 230 in |
Loader
| Clearance at Max Dump Height | 122 in |
|---|---|
| Bucket Breakout Force | 8,600 lb |
| Reach at Max Dump Height | 22 in |
