Volvo
New Holland
W110B
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
27 data points
Operating Specifications
| Operating Weight | 22,487 lb |
|---|---|
| Tire Size | 16X24/12 |
| Static Tipping Weight | 13,228 lb |
Engine
| Engine Model | D 70 A |
|---|---|
| Power Measured @ | 2,400 rpm |
| Gross Power | 157.0 hp |
| Number of Cylinders | 6 |
| Torque Measured @ | 1,200 rpm |
Hydraulic System
| Pump Flow Capacity | 52.9 gal/min |
|---|---|
| Raise Time | 7.0 s |
| Lower Time | 5.0 s |
| Relief Valve Setting | 1,990 psi |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 110 in |
| Wheelbase | 93 in |
| Width Over Tires | 95 in |
| Reach at Max Lift and Dump | 37 in |
| Length with Bucket on Ground | 222 in |
| Hinge Pin - Max Height | 137 in |
Transmission
| Max Speed - Forward | 26.1 mph |
|---|---|
| Max Speed - Reverse | 26.1 mph |
| Transmission Type | power shift |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 2.30 yd³ |
|---|---|
| Dump Clearance at Max Raise | 106 in |
| Bucket Width | 95 in |
