VolvoVolvo
A35E
Off-Highway Truck
44 specifications
1 / 5
Image 1 of 5
Specifications
37 data points
Operating Specifications
| Fuel Capacity | 74.0 gal |
|---|---|
| Tire Size | front 18.00-25 Radial or Cross-Ply - rear 20.5-25 |
| Engine Oil Capacity | 4.5 gal |
| Cooling System Fluid Capacity | 8.0 gal |
| Hydraulic System Fluid Capacity | 42.3 gal |
| Operating Voltage | 12 V |
| Transmission Fluid Capacity | 5.9 gal |
Engine
| Engine Model | TD 60B |
|---|---|
| Displacement | 334 in³ |
| Power Measured @ | 2,500 rpm |
| Gross Power | 170.0 hp |
| Net Power | 146.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged |
| Torque Measured @ | 2,000 rpm |
| Max Torque | 328 lb-ft |
Weights
| Total Empty | 33,951 lb |
|---|---|
| Front Axle - empty | 16,314 lb |
| Total Loaded | 74,737 lb |
| Front Axle - loaded | 22,046 lb |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Wheelbase | 170 in |
| Overall Length | 393 in |
| Overall Width | 100 in |
| Overall Height | 111 in |
| Dump Height | 226 in |
| Dump Ground Clearance | 29 in |
Transmission
| Max Speed | 18.6 mph |
|---|---|
| Transmission Type | Powershift |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Dump
| Rated Payload | 40,786 lb |
|---|---|
| Dump Angle | 63 ° |
| Raise Time | 21.0 s |
| Lower Time | 21.0 s |
| Capacity - Heaped | 15.09 yd³ |
| Capacity - Struck | 11.80 yd³ |
