Volvo
Caterpillar
434E
Backhoe Loader
37 specifications
1 / 5
Image 1 of 5
Specifications
47 data points
Operating Specifications
| Operating Weight 4wd | 24,013 lb |
|---|---|
| Fuel Capacity | 67.4 gal |
| Hydraulic System Fluid Capacity | 30.4 gal |
| Cooling System Fluid Capacity | 6.4 gal |
| Tire Size Front - 2wd / 4wd | 18.4-30 SGL |
| Operating Voltage | 24 V |
| Oil System Fluid Capacity | 3.2 gal |
| Alternator Supplied Amperage | 60 A |
| Turning Radius | 226 in |
| Transmission Fluid Capacity | 7.2 gal |
| Rear Axle Fluid Capacity | 6.0 gal |
| Front Axle Fluid Capacity | 6.0 gal |
Engine
| Engine Model | TD 48 GAE |
|---|---|
| Displacement | 293 in³ |
| Power Measured @ | 2,000 rpm |
| Gross Power | 120.7 hp |
| Net Power | 118.1 hp |
| Number of Cylinders | 4 |
| Aspiration | turbocharged |
| Torque Measured @ | 1,350 rpm |
| Net Max Torque | 343 lb-ft |
Hydraulic System
| Pump Flow Capacity | 45.0 gal/min |
|---|---|
| Relief Valve Pressure | 3,263 psi |
| Pump Type | two axial-flow piston pump |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Wheelbase | 100 in |
| Transport Width | 100 in |
| Transport Length | 319 in |
| Height to Top of Suspended Cab | 122 in |
Transmission
| Max Speed | 27.4 mph |
|---|---|
| Max Speed - Reverse | 15.9 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 3 |
| Transmission Type | Volvo BM HT90 powershift transmission |
Tires & Wheels
| Rear Tires Size | 18.4-30 SGL |
|---|
Backhoe
| Dig Depth | 182 in |
|---|---|
| Reach From Swivel | 251 in |
| Dig Depth - Extended | 223 in |
| Bucket Dig Force | 9,280 lb |
| Reach From Swivel - Extended | 289 in |
| Bucket Dig Force - Extended | 6,880 lb |
Loader
| Bucket Capacity | 2.00 yd³ |
|---|---|
| Clearance at Max Dump Height | 111 in |
| Bucket Breakout Force | 16,160 lb |
| Bucket Width | 99 in |
| Reach at Max Dump Height | 35 in |
| Dig Depth | 29 in |
