Volvo
New Holland
W110B
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
38 data points
Operating Specifications
| Operating Weight | 17,858 lb |
|---|---|
| Fuel Capacity | 45.0 gal |
| Tire Size | 15.5R25 |
| Hydraulic System Fluid Capacity | 28.1 gal |
| Static Tipping Weight | 10,803 lb |
| Operating Voltage | 24 V |
| Engine Oil Fluid Capacity | 3.0 gal |
| Rear Axle Oscillation | 24 ° |
| Alternator Supplied Amperage | 60 A |
| Cooling System Fluid Capacity | 5.9 gal |
Engine
| Engine Model | TD 40GA |
|---|---|
| Displacement | 244 in³ |
| Power Measured @ | 2,200 rpm |
| Net Power | 68.0 hp |
| Number of Cylinders | 4 |
| Torque Measured @ | 1,400 rpm |
Hydraulic System
| Pump Flow Capacity | 31.8 gal/min |
|---|---|
| Raise Time | 4.4 s |
| Lower Time | 3.3 s |
| Dump Time | 1.3 s |
| Relief Valve Setting | 3,771 psi |
| Pump Type | load sensing pressure compensated hydraulic system |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 119 in |
| Wheelbase | 109 in |
| Width Over Tires | 85 in |
| Reach at Max Lift and Dump | 42 in |
| Length with Bucket on Ground | 252 in |
| Hinge Pin - Max Height | 146 in |
Transmission
| Max Speed - Forward | 22.7 mph |
|---|---|
| Max Speed - Reverse | 22.7 mph |
| Transmission Type | hydrostatic |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Bucket
| Bucket Capacity - heaped | 2.00 yd³ |
|---|---|
| Dump Clearance at Max Raise | 109 in |
| Breakout Force | 13,620 lb |
| Bucket Width | 91 in |
